Chapter 2: Kaye ValProbe RT Hardware
ValProbe RT User Manual 10
Rigid Temperature RT Loggers
The Rigid Temperature RT Loggers have a temperature range from -85°C to 140°C. They are
a single sensor only, with a sensor tip length of 1.5”, 3”, 6”, or 9”, and have a diameter of 3mm
/ 0.118”.
Figure 13: Rigid Temperature RT Loggers
Bendable Temperature RT Loggers
Bendable Loggers are available in two versions, single and dual. They feature a temperature
range of -85 °C to 140°C. If used with an Insulating Canister, a range of 360°C is achievable.
Sensor tips are provided in 12”, 18”, 24”, 36” and 48”. Sensor tip diameter is 2.4mm, 0,98”.
To prevent breaking and/or stress on the inner conductors of the bendable Temperature
Logger probe, the following guidelines should be followed:
• Do not bend past the minimum bending radius which is 2x the diameter of the probe.
To ensure that the limit is not exceeded, Kaye recommends bending the probe around
a cylinder with a diameter of the Logger diameter.
• Avoid repeated bending of the probe at the same point.
• The probe should not be bent within one inch of the Logger body or one inch from
where the tip is welded to the probe.
Figure 14: Single Bendable
