KEB COMBIVERT F6 - Page 200

Status displays
200
© 2022 KEB Automation KG
ru75
global drive state
Bit 8…15
exception state display
Bit
Value
Mult.
Plaintext
Meaning
8…15
0
25
6
no exception
The adjacent lines are illustrative only (exam-
ples) of the values.
The meaning of the values is identical with ru01.
The complete list of all values and the descrip-
tion of the error messages can be found in the
chapter 4.3.1 Errors
3
ERROR overcurrent PU
4
ERROR overcurrent analog
…
…
116
ERROR GTR7 OC
117
ERROR GTR7 always ON
5.8.1.4 State of the ramp generator (4 Bit)
ru75
global drive state
Bit 16…19
ramp state display
Bit
Value
Mult.
Plaintext
Meaning
16…19
0
65536
pos acc inc
Positive output value,
positive acceleration is increased
1
pos acc
Positive output value
with constant positive acceleration
2
pos acc dec
Positive output value,
positive acceleration is decreased
3
neg acc inc
Negative output value,
negative acceleration is increased
4
neg acc
Negative output value
with constant negative acceleration
5
neg acc dec
Negative output value,
negative acceleration is decreased
6
ref eq out
Ramp output equal to ramp input
7
pos dec inc
Positive output value,
negative acceleration is increased
8
pos dec
Positive output value
with constant negative acceleration
9
pos dec dec
Positive output value,
negative acceleration is decreased
10
neg dec inc
Negative output value,
positive acceleration is increased
11
neg dec
Negative output value
with constant positive acceleration
12
neg dec dec
Negative output value,
positive acceleration is decreased
positive or negative acceleration describes the sign of the acceleration or decelera-
tion torque:
positive acceleration = forward acceleration or reverse deceleration
negative acceleration = reverse acceleration or forward deceleration
