8163A/B, 8164A/B, 8166A/B User’s Guide 43
Getting Started 1
How to Use the Numerical Keypad
You can use the Numerical Keypad to change the value of a parameter.
See How to Change the Value of a Parameter on page -54.
How to Use the Modify Knob
Figure 13 The Modify Knob
You can use the Modify Knob to navigate around the display. When you
turn the Modify Knob through one click, one action is performed.
Turning the Modify Knob clockwise moves the highlighted marker right
and then down. Turning the Modify Knob anti-clockwise moves the
highlighted marker left and then up.
You can use the Modify Knob to change the value of a parameter. See How
to Change the Value of a Parameter on page -54.
The Numerical Keypad is only available if you use the Keysight 8164A/B.
The Modify Knob is only available if you use the Keysight 8164A/B.
