N9030B PXA Signal Analyzer Service Guide 145
Instrument Messages
Condition Messages
Condition Errors 701 to 799, Operation
This series of errors corresponds to the bits in the STATus:OPERation register,
read with a STATus:OPERation? event query or a
STATus:OPERation:CONDition? query.
An event with the error number shown in the table means the condition has
been detected. When the condition is cleared, an event with the error number
plus 1000 is generated.
For example, error 721 indicates that the DC Coupled condition has been
detected; error 1721 indicates that condition has been cleared.
Unless otherwise noted in the Error or Warning column, these are status bits
only, with no corresponding error message or number
Err# Bit in
status
register
Message Error or
Warning
More Information
701 0 Calibrating status bit only
703 1 Settling status bit only
705 2 Ranging unused
707 3 Sweeping status bit only
709 4 Measuring status bit only
711 5 Waiting for Trigger status bit only
713 6 Waiting for Arm status bit only
715 7 unused
717 8 Paused status bit only
719 9 Source Sweeping status bit only
721 10 DC Coupled W
723 11 unused
725 12 Source Waiting for
Trigger
status bit only
727 13 unused
729 14 unused
