Keysight Technologies
N9030B PXA Signal Analyzer
Service Guide
4 RF Section Troubleshooting
(RF/Microwave Analyzers)
What You Will Find in This Chapter
The following information is found in this chapter:
1. Theory of operation of the RF section.
2. Isolating the cause of an hard ware problem by verifying the functionality
of assemblies in the RF section signal path.
The following sections are found in this chapter:
RF Section Description on page 148
Quick Check to Verify the Low Band Signal Path on page 154
Troubleshooting a Low Band Problem on page 157
Quick Check to Verify High Band RF Path on page 163
Troubleshooting a High Band Problem on page 167
Each section describes how the assembly works and gives information to
help you troubleshoot the assembly. Each description covers the purpose
of the assembly, describes the main components, and lists external
connections to the assembly.
