N9030B PXA Signal Analyzer
Service Guide
12 Hardware Options
What You Will Find in This Chapter
The following information is found in this chapter.
A25 Wideband Analog IF Troubleshooting - Option B1X and B85 on page
324
A26 Wideband Digital IF Troubleshooting - Option B1X and B85 on page
329
A25 Wideband Analog IF Troubleshooting - Option B2X and B5X on page
330
A26 Wideband Digital IF Troubleshooting - Option B2X and B5X on page
337
Option BBA Analog I/Q Baseband Inputs Description on page 338
Option RTS, Streaming on page 340
The PXA signal analyzer has a variety of hardware options that can be
purchased and installed at the time of new instrument sale, or as a post-sale
upgrade. Some of these hardware options require the installation of additional
hardware, and others require licensing hardware already present in the
standard instrument hardware configuration.
A current list of all instrument options and retrofit requirements is available on
the Keysight web site for the PXA signal analyzer at:
http://www.keysight.com/find/PXA_upgrades
Table 12-1 Hard ware Options
Option Description Additional Hardware or
License Only
Service Guide Section
ALV Auxiliary Log Video
(at rear panel Aux IF connector)
License Only Chapter 6, “Front End Control
Troubleshooting”
B25 25 MHz Analysis Bandwidth path License Only Chapter 7, “Analog/Digital IF
Troubleshooting”
