388 N9030B PXA Signal Analyzer Service Guide
Replaceable Parts
Replaceable Parts
W25 Cable, coax, Narrow Band IF Out, Front End Controller J900 to Analog
IF J100
8121-1865
W26 Cable, coax, Wideband IF Out, Front End Controller J901 to
Digital IF J15 (instruments without Option B1X, B2X, B5X)
8121-1919
W27 Cable, coax, Aux IF Out, Front End Controller J1100 to
rear panel Aux IF Out
8121-1859
W28 Cable, ribbon, Switched Filter control, Front End Controller J1300 to
Switched Filter J1
N9020-60064
W29 Cable, semi-rigid, Front Panel Ext Mixer connector to W75
(Option EXM)
N9020-20166
W30 Cable, coax, Ext IF Out, A13J13 to Front End Control J903
(Option 503, 508, 513, 526) (Option EXM)
8121-2027
Cable, coax, Ext IF Out, A13J13 to Front End Control J903
(Option 544, 550) (Option EXM)
8121-2025
W31 Cable, semi-rigid, 4.8GHz 2nd LO. Reference Assy, J703 to Synthesizer
Assy J4 (without EP0)
N9020-20021
W32 Cable, coax, 100 MHz, Reference Assy J706 to LO Synthesizer J10 8121-1401
W33 Cable, coax, 50 MHz Align, Front End Assy J6 to Reference Assy J705 8121-1940
W34 Cable, coax, 2400 MHz, Reference Assy J718 to Wide Band A-IF J301
(Option 1BX)
8121-0152
W35 Cable Assembly, flexible coax, A19J101, BBIQ Main Board to A16J707
Reference Board (Option BBA)
8121-1401
W36 Cable, coax, 300 MHz, Reference Assy J711 to Analog IF J300 8121-1861
W37 Cable, coax, External Reference IN, rear panel to Reference Assy J704 8121-1860
W38 Reserved
W39 Cable, coax, 100 MHz ref B, Reference Assy J716 to Digital IF J14 8121-1401
W40 Cable, coax, 250 MHz from Wideband A-IF J102 to Digital IF J15
(Option B1X)
8121-1401
W41 Cable, coax, 300 MHz from Front End Controller J901 to
Wideband Analog IF J101 (Option B1X)
8121-1865
W42 Cable, coax, 22.5 MHz IF Out, Analog IF J601 to D-IF J19 8120-8868
W43 Cable, ribbon interconnect from Analog IF J820 to Digital IF A3J30 N9020-60046
W44 Cable, ribbon, Wideband Analog IF J2 to Wideband Digital IF J504
(Option B1X)
8121-1854
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
