N9030B PXA Signal Analyzer Service Guide 29
Overview
Service Equipment You Will Need
Service Equipment You Will Need
There are certain things that will be required to troubleshoot, adjust, and test
the PXA Signal Analyzer. They include the following:
— Calibration Application Software
— Front End Controller Troubleshooting Kit
—USB Keyboard and Mouse
— USB Storage Device
—Test Equipment
Tools you will need
Figure 1-2 TORX Tool
Calibration Application Software
Information regarding the Keysight X-Series Signal Analyzer Calibration
Application Software can be found at the following web site:
www.keysight.com/find/calibrationsoftware
Description Keysight Part Number
TORX Hand Driver - Size T-8 8710-1614
TORX Hand Driver - Size T-10 8710-1623
TORX Hand Driver - Size T-20 8710-1615
9/16 inch nut driver 8720-0008
1/4 inch nut driver source locally
5/16 inch open-end wrench source locally
1/4 inch open-end wrench source locally
1/4 inch socket on 4 lb torque wrench source locally
cable puller 5021-6773
