318 N9030B PXA Signal Analyzer Service Guide
Front Panel/Motherboard Troubleshooting
A8 Motherboard Description
A8 Motherboard Troubleshooting
There are no troubleshooting procedures for this assembly. If the Motherboard
is suspect, it must be replaced.
Table 11-1
Motherboard
Connector
What Plugs In? Motherboard
Connector
What Plugs In?
J2 A7, Midplane J21 A16, Reference
J3 A7, Midplane J31/J32 Option Slots
J4 A7, Midplane J41/J42 Option Slots
J5 A7, Midplane J51/J52 Option Slots
J6 B3, Fan J61/J62 Option Slots
J7 B2, Fan J71/J72 Option Slots
J8 B1, Fan J81/J82 Option Slots
J9 Front Panel J91/J92 Option Slots
J11 A3, Digital I.F, analog signals J101 A14, LO Synthesizer
J12 A3, Digital I.F, analog signals J111 A15, Front End Control
