N9030B PXA Signal Analyzer Service Guide 387
Replaceable Parts
Replaceable Parts
W8 Cable, semi-rigid, Front End assy J2 to Low Band Switch J2
(Options 503, 508, 513, 526)
N9020-20101
Cable, semi-rigid, Front End assy J2 to Low Band Switch J2
(Options 544, 550)
N9020-20131
W9 Reserved
W10 Cable, semi-rigid, Switch 2 port 2 to YTF
(Options 503, 508, 513, 526 with Option LNP or MPB)
E4410-20163
W11 Cable, wire harness, YTF Control, Front End Controller J300 to YTF J1 N9020-60059
W12 Cable, wire harness, Preselector bypass switch control,
FE controller J801
(Option LNP / MPB, no B5X)
E4410-60159
Cable, wire harness, 4 switch control,
FE controller J801
(Option B5X)
N9030-60035
W13 Cable, semi-rigid, Switch 1 port 1 to AT1 6 dB Pad
(Options 503, 508, 513, 526 with Option LNP or MPB)
N9020-20210
W14 Cable, semi-rigid, YTF out to Switch 1 port 2
(Options 503, 508, 513, 526 with Option LNP or MPB)
E4410-20165
W15 Cable, semi-rigid, Switch 1 port C to Front End assy RF input. J9
(Options 503, 508, 513, 526 with Option LNP or MPB)
E4410-20164
W16 Cable, IF Out from Front End Assy J7 to Front End Control J902 8121-1862
W17 Spare
W18 Cable, semi-rigid, 2nd LO In, Reference Assy J702 to Front End Assy J1 N9020-20022
W19 Cable, semi-rigid, AUX LO Out from Front End Assy J3 to Switched
Filter Assy J6
N9020-20077
W20 Cable, semi-rigid, Front End Assy J4 To YTO
(Options 503, 508, 513, 526 - without EP0)
N9020-20018
Cable, semi-rigid, Front End Assy J4 To YTO
(Options 544, 550 - without EP0)
N9020-20152
W21 Cable, semi-rigid, LO Synthesizer Assy J20 to Front End Assy J5
(without EP0)
N9020-20019
W22 Cable, ribbon, Front End Assy control J12 to Front End Controller J102 E4410-60156
W23 Cable, ribbon, YTO Control, LO Synthesizer J25 to YTO N9020-60024
W24 Cable Assembly, ribbon cable, A18J1, BBIQ Interface Board to A19J1,
BBIQ Main Board (Option BBA)
8121-2090
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
