386 N9030B PXA Signal Analyzer Service Guide
Replaceable Parts
Replaceable Parts
Dress Cover N9020-00069
Impact Cover, front, plastic
N9020-40004
Rear Feet 5041-7903
Bottom Feet 5041-7906
Bottom Feet Key Locks 5021-2840
Strap Handle N9020-60253
End cap for Strap Handle 5041-7902
Blank label, silver, covers rear panel Wideband Digital Bus rectangle
holes when Option RTS is not present
N9030-80045
Spring Clip, secures flex cable to WB-DIF assy (Option B2X or B5X) N9030-00002
W1 Cable, ribbon 68 pin, Front panel Interface to Motherboard N9020-60216
W2 Cable, semi-rigid, RF Input to Attenuator A
(Options 503, 508, 513, 526)
N9020-20100
Cable, semi-rigid, RF Input to Attenuator A
(Options 544, 550)
N9020-20173
W3 Cable, semi-rigid, Cal In to attenuator, Reference Assy J701 to
Attenuator A
(Options 503, 508, 513, 526)
N9020-20023
Cable, semi-rigid, Cal In to attenuator, Reference Assy J701 to
Attenuator A
(Options 544, 550)
N9020-20072
W4 Cable, semi-rigid, Attenuator B to Attenuator A
(Options 503, 508, 513, 526)
N9020-20025
Cable, semi-rigid, Attenuator B to Attenuator A
(Options 544, 550)
N9020-20068
W5 Cable, Ribbon, Attenuator A/B to Front End Controller J800 E4410-60157
W6 Cable, semi-rigid, Attenuator B to Low Band Switch
(Options 503, 508, 513, 526 without Option MPB or LNP)
N9020-20024
Cable, semi-rigid, Attenuator B to Low Band Switch
(Options 544, 550 without Option MPB or LNP)
N9010-20004
W7 Cable, ribbon, Lowband Switch J4 to Front End Controller J700 N9020-60092
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
