N9030B PXA Signal Analyzer Service Guide 385
Replaceable Parts
Replaceable Parts
Bracket, Attenuator (used for both attenuators)
(Options 503, 508, 513, 526)
E4449-00103
Bracket, Attenuator (used for both attenuators)
(Options 544, 550)
N9020-00047
Bracket, Low Band Switch Assembly (Options 503, 508, 513, 526) N9020-00023
Bracket, Low Band Switch Assembly (Options 544, 550) N9020-00013
Bracket, Power Supply W1312-00131
Bracket, Wideband Extension Board (Option RTS) N9020-00067
Bracket, SW1 (Options 503, 508, 513, 526 with Option MPB) E4410-00104
Bracket, SW2 (Options 503, 508, 513, 526 with Option MPB) E4410-00110
Bracket, SW3 (Options 503, 508, 513, 526 with Option MPB) N9020-00022
Bracket, Bypass (Options 544, 550 with Options LNP or MPB) N9020-00021
Shield, YTO, Top N9020-00005
Shield, YTO, Bottom N9020-00006
Shield, Magnetic, Attenuator A (Options 544, 550) N9020-00043
Shield, Magnetic, Attenuator B (Options 544, 550) N9020-00044
Top Brace Assembly
(includes 4 each Vibration Mounts 0460-2725)
N9030-60005
Vibration Mounts 0460-2725
Spiral Wrap; 0.250 IN OD; 0.160 IN ID; for Digital IF cables 0890-0025
Cable tie, 0.062 - 0.625 dia 0.091 wide 1400-0249
Cable Clamp,.nylon, 0.375 wide 1400-1439
Edge Protector (for chassis left and right) 0400-0018
Fastener, Hook and Loop 0510-1303
Plug hole, Nylon, for 0.5 D hole (BNC size) 6960-0149
Plug hole, Nylon for 0.25 hole (SMA size) 6960-0076
Plug hole, dome head, Nylon for 0.875 hole 6960-0177
Cable Tie, .062 - 2 dia, .045 wide 1400-0507
Fan Guard, Steel 3160-0281
Rivet, Fan Mounting 0361-1272
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
