384 N9030B PXA Signal Analyzer Service Guide
Replaceable Parts
Replaceable Parts
EMI O-Ring 18.75 mm ID
Used between RF input connector and front frame
8160-1637
J2 EXT MIXER Connector (discard washer and nut, if supplied) 1250-1666
AT1 Attenuator, 6dB, coax, (8493C) connects to SW 2 and W13
(Option MPB)
08493-60026
SW1 Switch, Coax, used for Preselector Bypass
(Options 503, 508, 513, 526 with Option MPB)
N1810-60069
SW2 Switch, Coax, used for Preselector Bypass
(Options 503, 508, 513, 526 with Option MPB)
N1810-60069
SW3 Switch, Transfer, used for Low Noise Path
(Options 503, 508, 513, 526 with Option LNP)
87222-60026
Switch, Transfer, used for Low Noise Path
(Options 544, 550 with Option LNP)
87222-60029
SW4 Switch, Transfer, used for Microwave Preselector Bypass
(Options 544, 550 with Options MPB)
87222-60031
SW5 Switch, Coax, on Option B5X Front End Assembly N1810-60102
SW6 Switch, Coax, on Option B5X Front End Assembly N1810-60102
50 ohm Termination, SMA male used on A13 J8 1810-0118
Chassis Base N9020-00015
Gusset, Chassis (near RF input connector) W1312-00093
Chassis Side, Left (inner) W1312-00117
Chassis Side, Right (inner) W1312-00116
Card Guide (for chassis left and right) W1312-40001
Clamp, Ribbon Cable (attaches to right front chassis side) 5023-1397
Cable Clamp for coax cables (attaches to right rear chassis side) 5023-1379
Rear Frame N9020-00065
Bracket, Midplane W1312-00048
Bracket, Chassis Front W1312-00098
Bracket, Fan W1312-00118
Bracket, RF Side (right side outer) N9020-00014
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
To Next Page
