N9030B PXA Signal Analyzer Service Guide 383
Replaceable Parts
Replaceable Parts
A14 Synthesizer Assembly, Standard (Option EP1) N9020-60008
Synthesizer Assembly, (Option EP0) N9020-60227
A15 Front End Controller N9020-60172
Front End Controller (Option EP0) N9020-60295
A16 Reference Assembly, Standard (Option EP1) N9020-60188
Reference Assembly (Option EP0) N9020-60187
A17
BBIQ LED Board (Option BBA)
d
N9020-63095
A18 BBIQ Interface Board (Option BBA) N9020-60094
A19 BBIQ Main Board (Option BBA) N9020-60093
A20 YTO Assembly N9020-60009
A21 Reserved
A22 Reserved
A23 Reserved
A24 Reserved
A25 Wideband Analog IF (Option B1X) N9020-60044
Wideband Analog IF (Option B2X or B5X) N9020-60043
A26 Wideband Digital IF (Option B1X or B2X) N9020-60311
A27 Wideband Digital IF (Option B5X) N9020-60311
A28 Wideband DIF Extension Board (Option RTS) N9020-60272
A28A1 Gasket, EMI for WB DIF Extension (Option RTS) N9020-20178
B1, B2, B3 Fan 3160-4199
FL2 7.2 GHz bandpass filter (connects to semi rigid from A14) (Option EP0) 9135-6218
FL3 5.7 GHz bandpass filter on A13 (Option B5X) 9135-6217
J1 Type-N Input Connector Assembly
(Options 503, 508, 513, 526 without Option C35)
N9039-60030
3.5 mm Input Connector Assembly
(Option C35)
N9020-60196
2.4 mm Input Connector Assembly
(Options 544, 550)
N9030-60011
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
