18 N9030B PXA Signal Analyzer Service Guide
Overview
Instrument Option Descriptions
Option Description Notes
503 3 Hz to 3.6 GHz frequency range
508 3 Hz to 8.4 GHz frequency range
513 3 Hz to 13.6 GHz frequency range
526 3 Hz to 26.5 GHz frequency range
544 3 Hz to 44 GHz frequency range
550 3 Hz to 50 GHz frequency range
ALV Auxiliary Log Video
(at rear panel Aux IF connector)
B25 25 MHz information bandwidth
B40 40 MHz information bandwidth in addition to 25 MHz BW
B85 85 MHz information bandwidth
B1X 140 MHz information bandwidth
BBA I/Q Baseband Inputs, Analog
CRP Arbitrary IF Output
(10 MHz to 75 MHz programmable, Aux IF connector on rear panel)
CR3 2nd IF Out (Aux IF connector on rear panel)
C35 APC 3.5 mm Connector With Option 526 only
EA3 Electronic Attenuator
EDP Enhanced Display Package Spectrogram, Trace Zoom
EMC Software only. Provides EMI detectors and BWs.
EP1 Enhanced Phase Noise Performance Included on all units
EXM External Mixing
FSA Fine Step Attenuator Included on all units
FS1 Fast Sweep Improves sweep speed in
swept-tuned mode
LFE Low Frequency Enabled
(allows frequency range to 3 Hz)
Included on all units
LNP Low Noise Path
(provides enhanced DANL and SHI performance above 3.6 GHz)
MPB Preselector Bypass
(bypasses the Preselector filter used above 3.6 GHz)
NFE Noise Floor Extension Included on all units before
August 2013
NF2 Noise Floor Extension Included on all units starting
August 2013
NUL IM Nulling Included on all units
PFR Precision Frequency Reference Included on all units
P03 Preamp, 100 kHz to 3.6 GHz
P08 Preamp, 100 kHz to 8.4 GHz
P13 Preamp, 100 kHz to 13.6 GHz
