N9030B PXA Signal Analyzer Service Guide 381
Replaceable Parts
Replaceable Parts
A1A3 Liquid Crystal Display 10.6-in w/PCAP Touch 1280X768-Pixels 2090-1103
A1A4 Keyboard, PCA N9020-63275
A1A5 Main Keypad N9020-40001
A1MP1 Overlay, solid left N9020-80164
A1MP2 Overlay, Keyboard
N9020-80127
A1MP3 Frequency Label, 3.6 GHz N9030-80030
A1MP4 Frequency Label, 8.4 GHz N9030-80031
A1MP5 Frequency Label, 13.6 GHz N9030-80032
A1MP6 Frequency Label, 26.5 GHz N9030-80033
A1MP7 Frequency Label, 44 GHz (Option 544) N9030-80035
A1MP8 Frequency Label, 50 GHz (Option 550) N9030-80036
A1MP9 Display hold down (compression pad) N9020-40003
A1MP10 Bracket front panel shield N9020-00064
A1MP11 Display Bracket, Front Panel N9020-00063
A1MP13 RPG Knob W1312-40179
A1MP14 Shield N9020-00066
A1MP16 Core Bracket (Option BBA) N9020-00012
A1MP17 Overlay, BBIQ Bottom (Option BBA) N9020-80166
A1MP18 Overlay, BBIQ Top (Option BBA) N9020-80163
A1W1 Flex Circuit, Display to Front Panel Control Board N9020-60273
A1W2 Cable Assembly, Backlight N9020-60217
A2 Analog IF Assembly N9020-60290
A3 Digital IF Assembly N9020-60016
A3W1 Cable Assembly, Smart Noise Source (Wire Harness) N9020-60090
A4 CPU Board (without A5 drive or drive tray parts, includes battery and
SD memory card)
N9020-60247
A4A1 Disk Drive Interconnect Board W1312-63079
A4A2 Memory card, SD 1819-1069
A4BT1 Battery, CPU, 3V, LI Manganese Dioxide 1420-0356
(CR2032)
Table 15-1 All Replaceable Parts
Reference
Designator
Description Part Number
