TOS3200 15
No. Name Function
Page
1
DANGER lamp Illuminates while a test is in progress. 5, 62
2
A/B terminal
Measurement terminal. Connect the test lead or probe to this
terminal.
If this terminal is required depending on the test mode, the LED
above the terminal will illuminate.
5, 46
3
REMOTE connector
A dedicated connector used to connect the HP21-TOS option
probe.
49
4
Display
Displays various types of information such as settings and
measured values.
32
5
START switch Starts the test. 62
6
STOP switch Stops the test. 66
7
AC LINE OUT EUT Supplies the power applied to the AC inlet for the EUT. 42
8
Ground terminal
Connect the ground wire when connecting a two-prong cord with a
ground wire to AC LINE OUT.
5, 42
9
LINE ON key
Turns the output of AC LINE OUT. The LED above the key
illuminates while the output is on.
44
10
LOCAL key Switches between the remote and local modes. 102
KEY LOCK key Disables only the operations that change the settings. 36
11
F1 〜 F5 key
Function keys corresponding to the menu that appears on the
screen.
33
12
SHIFT key Calls up the functions marked in blue characters.
−
13
Leg and stand Allows you to lift up the front panel side of the unit. 26
14
POWER switch
Turn the power on ( ) or off ( ).
29
15
MANUAL key Selects the operation mode. 37
16
AUTO key Selects the program test.
76
EDIT key Edits the test conditions of the program test.
17
RECALL key Recalls settings from the panel memory.
38
STORE key Stores the settings to the panel memory.
18
key
Moves the cursor up.
34
key
Increases the screen brightness.
36
19
key
Moves the cursor to the left.
34
PREV key Returns to the previous screen.
20
key
Moves the cursor down.
34
key
Decreases the screen brightness.
36
21
key
Moves the cursor to the right.
34
NEXT key Moves to the next screen.
22
Rotary knob Changes the settings. 35
23
SYSTEM key Displays the system settings. 200
I/F key Displays the interface settings. 102
24
RMT LED
Illuminates when the TOS3200 is operating in remote control
mode.
102
25
ENTER key Confirms the panel memory to be recalled. 38
See
