Robot control box
Chapter 3 - page 30
M-HE.002.1003
The purpose of this function is to reset the cleaning of the separation pipeline
and to switch off the lamp underneath the corresponding button.
Message indicating whether or not the separation pipeline will be cleaned
during the next main cleaning.
Sensor of the cleaning tank indicates the water level by means of
conductivity.
Data for servicing operations.
This option is currently not in use.
In this screen the valve for overpressure in the tank with cleaning agent can
be switched open. While during cleaning the vacuum level is lower, a slight
overpressure (approx. 0,5 bar) in the tank with cleaning liquid is required to
distribute the water sufficiently quick.
If pressure is exerted on the tank with cleaning water, the piping for the
discharge of steam from the cleaning tank must be closed by a valve. This
can be done in this screen.
Lamp cleaning on
Separation line
lamp
off
Dump cleaning
no
Tank high yes
Tank low no
Tank empty yes
Buffer yes
Temperature ok yes
Pressure no
Alarm 240V yes
Free2 no
open
TEST CRS
closed
on
Pressure on tank
off
on
Steampipe valve
off
