Base Sensor Test
Use the Base sensor test to verify that the sensors located inside the printer are working correctly.
The following sensors can be checked using this test:
• Input
• Exit
• Narrow Media
• Front Door
CAUTION—SHOCK HAZARD: The sensor may be electrically energized. To avoid the risk of injury use a non-
conductive implement to toggle the sensors.
To run the Base sensor test:
1 From the Diagnostics menu, navigate to Base Sensor Test.
2 Choose a sensor.
3 Manually actuate the sensor to verify that it toggles. If the sensor does not toggle, then it is malfunctioning.
Sensor Values
Input
Exit
Front Door
Open
Closed
Narrow Media Narrow
Wide
4 Press X to exit the test.
Device Tests
Flash Test
This test verifies the condition of the flash device by writing data to it and then reading data from it.
Warning—Potential Damage: This test deletes all data on the flash device.
1 From the Diagnostics menu, navigate to:
DEVICE TESTS > Flash Test
2 Files will be lost. Go/Stop? appears.
3 Do any of the following:
• Press OK to continue.
• Press X to cancel.
4 When the test starts, Flash Test Testing… appears. The test cannot be stopped or canceled after it has
begun.
5 After the test is complete, a message appears indicating a pass or fail result.
4514-420, -430
Service menus
116
