Lexmark MS410 series

4 Remove the five screws (B) securing the controller board.
B
Toner cartridge smart chip contact removal
1 Remove the right cover. See “Right cover removal” on page 162.
2 Disconnect the cable JARW1 from the controller board.
3 Remove the two screws (A).
A
4514-420, -430
Repair information
165
