Lexmark MS410 series Service Manual

Skewed print
) )
ABCDE
ABCDE
ABCDE
Actions Yes No
Step 1
a POR into the Diagnostics menu and perform a print test:
Diagnostics Menu > Print Tests > Tray 1
b Adjust the margins if necessary:
Diagnostics Menu > Registration
Does the error remain?
Go to step 2. The problem is solved.
Step 2
Does the skew appear every two pages?
Go to step 9. Go to step 3.
Step 3
a Check the media source.
b If the media is from tray 1, go to step 4.
If the media is from the MPF, go to step 6.
Step 4
Make sure the pick tires are free of debris. Check for wear or damage.
Are they free of wear or damage?
Go to step 5. Replace the pick tires.
Step 5
Check the lift plate on the input tray for damage.
Is it free of damage?
Go to step 11. Replace the input tray.
Step 6
Make sure the MPF pick roller and separator pad are free of debris. Check
for wear or damage.
Are they free of wear or damage?
Go to step 7. Replace the MPF pick
roller and separator
pad. See “MPF pick
roller removal” on
page 181 and
“Separator pad
removal” on page
189.
Step 7
Check the MPF gearbox for wear or damage.
Is it free of wear or damage?
Go to step 8. Replace the MPF
gearbox. See “MPF
gearbox removal” on
page 151.
4514-420, -430
Diagnostic information
42
