Lexmark MS410 series

Rear side removals
Dust cover removal
1 Press the latches on each side of the dust cover.
2 Remove the dust cover.
2
1
Rear door and cover removal
1 Position the printer so that it sits on either its left or right side.
2 Open the rear door at an angle of 45 degrees.
4514-420, -430
Repair information
207
