Lexmark MS410 series

3 Remove the four screws (A), and then remove the jam access cover.
A
Front door removal
Note: This is not a FRU.
1 Remove the right cover. See “Right cover removal” on page 162.
2 Disconnect the cable JOPP1 or JOPP2 from the controller board.
3 Disconnect the cable JCVR1 from the controller board.
4514-420, -430
Repair information
183
