Lexmark MS410 series

6 Remove the four screws (A) securing the duplex.
A
Note: The duplex link (B) is part of the FRU.
B
Duplex sensor and input sensor removal
1 Remove the left cover. See “Left cover removal” on page 146.
2 Remove the right cover. See “Right cover removal” on page 162.
4514-420, -430
Repair information
194
