Parts catalog
Legend
The following column headings are used in the parts catalog:
• Asm‑index—Identifies the item in the illustration.
• Part number—Identifies the unique number that correlates with the part.
• Units/mach—Refers to the number of units actually used in the base machine or product.
• Units/FRU—Refers to the number of units in a particular FRU.
• Description—A brief description of the part.
The following abbreviations are used in the parts catalog:
• NS (not shown) in the Asm‑index column indicates that the part is procurable but is not pictured in the illustration.
• PP (parts packet) in the Description column indicates that the part is contained in a parts packet.
4514-420, -430
Parts catalog
