Lexmark MS410 series

5 Remove the spring (B) and the fuser gear (C).
BC
MPF solenoid removal
1 Remove the left cover. See “Left cover removal” on page 146.
2 Remove the main drive gearbox. See “Main drive gearbox removal” on page 147.
3 Remove the screw (A).
4514-420, -430
Repair information
149
