Lexmark MS410 series

7 Remove the two screws (A) securing the reverse solenoid.
A
ACM clutch removal
1 Remove the left cover. See “Left cover removal” on page 146.
2 Remove the main drive gearbox. See “Main drive gearbox removal” on page 147.
3 Position the printer on its rear.
4 Use a small flat-head screwdriver to block the roller (A) and prevent the shaft from rotating.
4514-420, -430
Repair information
155
