Lexmark MS410 series

6 Remove the two screws (B) securing the fuser.
A B
A
Top side removals
Top cover removal
1 Remove the right cover. See “Right cover removal” on page 162.
2 Remove the left cover. See “Left cover removal” on page 146.
3 Remove the rear door and cover. See “Rear door and cover removal” on page 207.
4 Open the front door.
4514-420, -430
Repair information
212
