Lexmark MS410 series Service Manual

Option tray ACM motor service check
Action Yes No
Step 1
Check the cable J11 on the option tray controller card.
Is it properly connected?
Go to step 2. Reseat the cable.
Step 2
a Remove the option tray insert and bypass the tray present sensor.
b POR into the Diagnostics Menu and perform a feed test:
Diagnostics Menu > Feed Test > choose an option tray
c Check the ACM for proper operation.
Does the ACM freely rotate three times before displaying a jam message?
Go to step 3. Replace the ACM
assembly. See “ACM
assembly removal” on
page 217.
Step 3
Is the ACM gear free of wear or damage?
Contact the next level
of support.
Replace the ACM
assembly. See “ACM
assembly removal” on
page 217.
Option tray controller card service check
Action Yes No
Step 1
Check all connections to the option tray controller card.
Are the properly connected?
Go to step 2. Reseat the cables.
Step 2
Check printer’s firmware level.
Is it up to date?
Go to step 3. Update the firmware.
Step 3
Replace the option tray.
Does the error remain?
Contact the next level
of support.
The problem is solved.
4514-420, -430
Diagnostic information
98

Lexmark MS410 series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 40 ppm
Duplex Printing	Standard
Processor Speed	800 MHz
Warranty	1-year limited warranty
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Input Capacity	250-Sheet Input
Output Capacity	150 sheets
Mobile Printing	Lexmark Mobile Print
Operating System Compatibility	Windows, macOS, Linux
Dimensions	15.7 x 15.0 x 10.3 inches
Weight	31.0 lbs
Recommended Monthly Page Volume	750 - 3, 500 pages
