Lexmark MS410 series

5 Remove the two screws (B) securing the fan to the fan mount.
B
Controller board removal
1 Remove the right cover. See “Right cover removal” on page 162.
2 Disconnect all cables from the controller board.
3 Remove the screw (A) from the rear side of the printer.
A
4514-420, -430
Repair information
164
