Printer hardware errors
1xx error messages
Error code Description Action
111.00 Pel clock check failed. Go to “111.xx LSU service check” on page 83.
111.01 Downlevel ASIC detected.
111.31 Printhead never delivered HSYNCs.
111.32 Printhead lost HSYNCs.
111.40 Wrong printhead installed
111.50 Open-loop printhead error, open-loop sweep state.
111.51
111.52 Open-loop printhead error, check prelim amp state.
111.53 Open-loop printhead error, enable amp Kp state.
111.54 Closed-loop printhead error, amp Kp failed to
converge.
111.55 Closed-loop printhead error while waiting for amp Kp
to converge.
111.56 Closed-loop printhead error, amp Ki failed to
converge.
111.57 Closed-loop printhead error while waiting for amp Ki
to converge.
111.58 Closed-loop printhead error, load scan regs state.
111.59 Closed-loop printhead error, forward and reverse
capture times differ by too much.
111.60 Closed-loop printhead sweep error, check sweep
accuracy state.
111.61 Printhead drive control out of range due to an
external event beyond what the control is designed
to handle.
111.62 Closed-loop printhead error, off-resonant PI effort
state.
111.63 Timed out on POR sweep.
111.64 Attempted to exceed open loop drive limits.
111.65
111.66 Failed alignment of printhead.
111.67
111.68 Too many fake HSYNCs while aligning printhead.
111.69
4514-420, -430
Diagnostic information
80
