Lexmark MS410 series Service Manual

5 While blocking the roller, remove the screw (B).
B A
6 Pull out the ACM clutch, and cut cable close to the clutch to detach it.
Installation notes:
a Pull the cable to remove any slack, and remove any shrink tubing holding the wires together.
4514-420, -430
Repair information
156

Lexmark MS410 series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 40 ppm
Duplex Printing	Standard
Processor Speed	800 MHz
Warranty	1-year limited warranty
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Input Capacity	250-Sheet Input
Output Capacity	150 sheets
Mobile Printing	Lexmark Mobile Print
Operating System Compatibility	Windows, macOS, Linux
Dimensions	15.7 x 15.0 x 10.3 inches
Weight	31.0 lbs
Recommended Monthly Page Volume	750 - 3, 500 pages
