Assembly 1: Covers
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8520 1 1 Dust cover (250sheet tray) “Dust cover removal” on page 207
2 40X8054 1 1 Rear door and cover “Rear door and cover removal” on
page 207
3 40X8052 1 1 Right cover “Right cover removal” on page 162
4 40X8056 1 1 Front access cover “Front access cover removal” on
page 186
5 40X9148 1 1 Cartridge plunger “Cartridge plunger removal” on
page 171
6 40X8303 1 1 250-sheet tray N/A
7 40X8302 1 1 MPF assembly (50 sheets) “MPF assembly removal” on
page 178
8 40X8051 1 1 Nameplate “Nameplate removal” on page 175
9 40X8059 1 1 Control panel assembly
Note: Does not include the UICC.
“Control panel assembly removal”
on page 175
“UICC removal” on page 177
10 40X8064 1 1 Bezel (MS410d) “Bezel removal” on page 174
10 40X8065 1 1 Bezel (MS410dn) “Bezel removal” on page 174
11 40X8053 1 1 Left cover “Left cover removal” on page 146
12 40X8055 1 1 Top cover “Top cover removal” on page 212l
4514-420, -430
Parts catalog
228
