Lexmark MS410 series Service Manual

Assembly 2: Electronics 1
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8081 1 1 Laser scanning unit “Laser scanning unit (LSU) removal” on
page 213
2 40X8343 1 1 Fuser, 100 V “Fuser removal” on page 211
2 40X8023 1 1 Fuser, 110 V “Fuser removal” on page 211
2 40X8024 1 1 Fuser, 220 V “Fuser removal” on page 211
3 40X8050 1 1 Narrow media/bin full sensor “Narrow media/bin full sensor removal”
on page 208
4 40X8276 1 1 Cooling fan “Cooling fan removal” on page 163
5 40X8027 1 1 Controller board (MS410d) “Controller board removal” on page 164
5 40X8028 1 1 Controller board (MS410dn) “Controller board removal” on page 164
6 40X8280 1 1 Front input guide “Front input guide removal” on page 187
7 40X8300 1 1 MPF solenoid “MPF solenoid removal” on page 149
8 40X8301 1 1 Reverse solenoid “Reverse solenoid removal” on page 154
9 40X8291 1 1 Control panel assembly “Control panel assembly removal” on
page 175
“UICC removal” on page 177
4514-420, -430
Parts catalog
230
