Lexmark MS410 series Service Manual

Assembly 4: Frame
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8393 1 1 Transfer roll “Transfer roll removal” on page 170
2 40X8298 1 1 Redrive assembly “Redrive assembly removal” on
page 210
3 40X8299 1 1 Front mounts “Left front mount removal” on
page 167
“Right front mount removal” on
page 168
4 40X8275 1 1 Duplex assembly “Duplex removal” on page 193
5 40X8296 2 1 Pick tire N/A
6 40X8260 1 1 ACM assembly “ACM assembly removal” on
page 202
7 40X8295 1 1 MPF pick roller and Separator pad “MPF pick roller removal” on
page 181
“Separator pad removal” on page
189
8 40X8279 1 1 Jam access cover “Jam access cover removal” on
page 182
9 40X8278 1 1 MPF gearbox “MPF gearbox removal” on page
151
10 40X8277 1 1 Duplex gear assembly “Duplex gear assembly removal” on
page 160
11 40X8265 1 1 ACM clutch “ACM clutch removal” on page 155
12 40X8083 1 1 Cartridge gearbox “Cartridge gearbox removal” on
page 160
13 40X8085 1 1 Main drive gearbox “Main drive gearbox removal” on
page 147
NS 40X8394 1 1 Screw kit N/A
4514-420, -430
Parts catalog
234
