Lexmark MS410 series

Assembly 5: Option trays
Asm-index P/N Units/opt Units/FRU Description Removal procedure
1 40X8287 1 1 250-sheet tray N/A
1 40X8286 1 1 550-sheet tray N/A
2 40X8520 1 1 Dust cover, 250‑sheet tray “Dust cover removal” on page 207
2 40X8521 1 1 Dust cover, 550‑sheet tray “Dust cover removal” on page 207
3 40X8262 1 1 ACM assembly “ACM assembly removal” on page 217
4 40x8443 1 1 Pick roller assembly “Pick roller removal” on page 214
5 40X8444 1 1 Separator roll assembly “Separator roll assembly removal” on page
215
6 40X8305 1 1 250-sheet tray insert N/A
6 40X8086 1 1 550-sheet tray insert N/A
4514-420, -430
Parts catalog
236
