202 paper jam messages
Error code Description Action
202.01 Exit sensor is covered during warm up. Go to “Sensor (fuser exit) jam service check” on
page 60.
202.03 Media did not reach the fuser exit sensor.
202.05 Fuser exit sensor covered too long by the current
sheet.
202.07 Fuser exit sensor covered too long by the previous
sheet.
202.13 Restart attempted after an internal jam without cover
open. Close event. Likely that the jam was not actually
cleared.
202.14 Expected banner sheet ( assumed wide ) not detected
by narrow media sensor, possible accordion jam,
unsupported narrow banner media, or missing signal.
202.16 Page at fuser nip before fuser started ramping toward
desired. Indicates code may be receiving more hall
interrupts than intended.
202.17 Page at fuser nip before fuser reached acceptable
operating temperature. Page arrived at fuser earlier
than expected, so it was probably staged.
202.22 Cartridge Motor - Motor Underspeed Error. Motor
made it to closed loop steady state, but then detected
speed was below threshold.
202.28 Exit sensor bounce issue.
202.32 The sheet is too long to be duplexed. The blow
through is enabled.
Go to “Duplex service check” on page 62.
202.36 Long paper or shingled multi feed stopped before
sending to duplex.
202.43 During warm up flush, media that passed the input
sensor failed to reach the exit sensor.
Go to “Sensor (fuser exit) jam service check” on
page 60.
202.45 During warm up flush, sheet detected too long over
exit sensor.
4514-420, -430
Diagnostic information
59
