Lexmark MS410 series Service Manual

Action Yes No
Step 24
a Upgrade the firmware if it was not upgraded in a previous step.
Note: Contact your next level of support for the correct firmware
level to use.
b POR the printer.
c Send the printer a print job.
Does the error remain?
Go to step 25. The problem is solved.
Step 25
a Replace the faulty ISP option.
b POR the printer.
Does the error remain?
Go to step 31. Go to step 26.
Step 26
Are there any more ISP options to install?
Go to step 27. The problem is solved.
Step 27
a Install the next ISP option.
b POR the printer.
Does the error remain?
Go to step 29. Go to step 28.
Step 28
Run a job to test the option.
Does the error remain?
Go to step 29. Go to step 26.
Step 29
a Upgrade the firmware if it was not upgraded in a previous step.
Note: Contact your next level of support for the correct firmware
level to use.
b POR the printer.
c Send the printer a print job.
Does the error remain?
Go to step 30. Go to step 26.
Step 30
a Replace the faulty ISP option.
b POR the printer.
Does the error remain?
Go to step 31. Go to step 26.
4514-420, -430
Diagnostic information
93

Lexmark MS410 series Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 40 ppm
Duplex Printing	Standard
Processor Speed	800 MHz
Warranty	1-year limited warranty
Print Resolution	1200 x 1200 dpi
Connectivity	USB, Ethernet
Input Capacity	250-Sheet Input
Output Capacity	150 sheets
Mobile Printing	Lexmark Mobile Print
Operating System Compatibility	Windows, macOS, Linux
Dimensions	15.7 x 15.0 x 10.3 inches
Weight	31.0 lbs
Recommended Monthly Page Volume	750 - 3, 500 pages
