LSIS S100 User Manual

158
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
value
Property* V/F SL Ref.
21 0h1115
Select speed
unit
Hz/Rpm Sel
0
Hz Display
0:Hz
Display
O O I/P p.78
1
Rpm
Display
22
2
0h1116
(+) Torque
Gain
(+) Trq Gain
50.0–150.0[%]
100[%] O X I -
23
2
0h1117 (-)Torque Gain (-) Trq Gain 50.0–150.0[%] 80.0[%] O X I -
24
2
0h1118
(-)Torque
Gain0
(-) Trq Gain0
50.0–150.0[%]
80.0[%] O X I -
25
2
0h1119
(-)Torque
Offset
(-) Trq Offset 0.0-100.0[%] 40.0[%] O X I -
80 0h1150
Select ranges
at power input
-
Select ranges
inverter
displays at
power input
0: run
frequency
O O I/P -
0
Run
frequency
1
Acceleratio
n time
2
Decelerati
on time
3
Command
source
4
Frequency
reference
source
5
Multi-step
speed
frequency1
6
Multi-step
speed
frequency2
7
Multi-step
speed
frequency3
8
Output
current
9
Motor RPM
10
Inverter DC
voltage
11
User select
signal
(DRV-81)
2
Displayed when DRV-10 is set to 1 (Yes)
