LSIS S100 User Manual

174
Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
33
29
0h1421
PM D-axis
back-EMF
estimation
gain [%]
PM EdGain
Perc
0~300.0[%] 100.0 X X P -
34
29
0h1422
PM Q-axis
back-EMF
estimation
gain [%]
PM EqGain
Perc
0~300.0[%] 100.0 X X P -
35
29
0h1423
Initial pole
position
detection
retry
number
PD Repeat
Num
0~10 2 X X P -
36
29
0h1424
Initial pole
position
detection
pulse
interval
Pulse
Interval
1~100 20 X X P -
37
29
0h1425
Initial pole
position
detection
current
level [%]
Pulse
Curr %
10~100 15 X X P -
38
29
0h1426
Initial pole
position
detection
voltage
level [%]
Pulse Volt %
100~4000 500 X X P -
39
29
0h1427
PM dead
time range
[%]
PMdeadBan
d
Per
50.0~100.0 100.0 X X P -
40
29
0h1428
PM dead
time
voltage [%]
PMdeadVol
t
Per
50.0~100.0 100.0 X X P -
41
29
0h1429
Speed
estimator P
gain1
PM SpdEst
Kp
0~32000 100 X X P -
42
29
0h142A
Speed
estimator I
gain1
PM SpdEst
Ki
0~32000 10 X X P -
43
29
0h142B
Speed
estimator P
gain2
PM SpdEst
Kp 2
0~32000 300 X X P -
29
Displayed when DRV-09 (Control Mode) is set to 6 (PM Sensorless).
