Manitowoc Published 10-01-2012, Control # 045-08 3-35
777 SERVICE MANUAL ELECTRIC SYSTEM
3
CONNECTOR PIN IDENTIFICATION
This section is provided to assist service and maintenance
personnel in identifying connector pins for all Brad Harrison
type connectors used on Manitowoc cranes:
• Extension cords with plug on both ends — M (male) one
end and F (female) other end.
• Cords with plug on only one end — either M (male) or F
(female).
• Receptacles — either M (male) or F (female).
Mini-Change Type Connectors
2-Pole Plugs
Extension:
Plug With Cord:
Receptacle:
Length Plug Part #
3 ft (0.9 m) M/F 477485
3 ft (0.9 m) M/F A02087
6 ft (1.8 m) M/F 477486
6 ft (1.8 m) M/F 477491
8 ft (2.4 m) M/F 477390
10.4 ft (3.1 m) M/F 477391
12 ft (3.7 m) M/F 477487
12 ft (3.7 m) M/F 477492
12 ft (3.7 m) M/F 911046
15 ft (4.6 m) M/F 477493
15.4 ft (4.7 m) M/F 477392
19.4 ft (5.9 m) M/F 477393
20.4 ft (6.2 m) M/F 477394
21.4 ft (6.5 m) M/F 477395
24 ft (7.3 m) M/F 477338
25.4 ft (7.7 m) M/F 477396
30.4 ft (9.6 m) M/F 477397
35 ft (10.7 m) M/F 477479
40.4 ft (12.3 m) M/F 477398
1-White
1-White
2-Black
Male
2-Black
Female
A1182
FIGURE 3-16
60 ft (18.3 m) M/F 477438
65 ft (19.8 m) M/F 911031
70 ft (21.3 m) M/F 477494
130 ft (40.0 m) M/F 477354
130 ft (40.0 m) M/F 477562
150 ft (45.7 m) M/F 477561
205 ft (62.5 m) M/F 911028
210 ft (64.0 m) M/F 477371
325 ft (99.1 m) M/F 477420
Length Plug Part #
3 ft (0.9 m) M 572334
3 ft (0.9 m) F 572444
3 ft (0.9 m) M 572514
3 ft (0.9 m) F 572518
3 ft (0.9 m) M 911879
6 ft (1.8 m) M 572335
6 ft (1.8 m) F 572485
6 ft (1.8 m) F 572515
6 ft (1.8 m) M 572592
12 ft (3.7 m) M 572336
12 ft (3.7 m) F 572345
12 ft (3.7 m) F 572573
15 ft (4.6 m) M 572416
15 ft (4.6 m) F 572497
15 ft (4.6 m) F 572509
20 ft (6.1 m) F 572406
20 ft (6.1 m) M 572572
20 ft (6.1 m) M 572574
30 ft (9.1 m) F 477389
50 ft (15.2 m) F 572407
100 ft (30.5 m) F A05250
Plug Part #
F 589650
F 90° 589651
M 589654
M 90° 589944
Length Plug Part #
To Next Page
