Manitowoc Published 10-01-2012, Control # 045-08 10-33
777 SERVICE MANUAL TROUBLESHOOTING
10
Test 5 – Cleaning and Adjusting the Engine RPM Transducer (Past Production)
Loosen the locking nut and remove the threaded transducer
from the flywheel housing. Clean any metallic debris from
the magnetic pickup on the transducer with a cleaning
solvent. Re-install the transducer so the magnetic pickup
makes contact with the flywheel. Loosen transducer 1/4 turn
and secure the lock nut.
Item Description
1Engine
2 RPM transducer
FIGURE 10-7
P564
2
1
