MIMAKI CFL-605RT - Workpiece and Blade Compatibility

1-10
Blades and Workpieces
The types of workpiece that can be cut and the blade types that can be used differ according to the unit.
Workpiece Types that Can be Cut (Guide)
Blade Types that Can Be Used
Work Cutter Type Tool Type
Unit
Felt
Mat
Hard
Ｍａｔ
Cutt
ing
Mat
A B
Coated board
200g/m
2
~600g/m
2
Cutter holder C with edge
(SPA-0267)
○○
High-speed steel blade
30°(SPB-0043)
Tangential cutter holder 2N
(SPA-0261)
○○
Carbide blade 30° (SPB-0045)
Woodlac panel Carbide blade 7x15
(SPB-0075)
(
Reciprocating cutter )
Reciprocating cutter holder 07L
(SPA-0260)
○○
Styrene board
Corrugated cardboard F, G
High-speed steel blade
30°(SPB-0043)
Carbide blade 30° (SPB-0045)
Tangential cutter holder 2N
(SPA-0261)
○○
PET pouch
Sandblasted rubber
Label paper/ Film
High-speed steel blade
30°(SPB-0043)
Carbide blade 30 °(SPB-0045)
Tangential cutter holder 2N
(SPA-0261)
○○
Swivel Blade(SPB-0030) Cutter holder(SPA-0090)
○○
PVC film Swivel Blade(SPB-0030) Cutter holder(SPA-0090)
○○
Artificial leather
High-speed steel blade
30°(SPB-0043)
Carbide blade 30° (SPB-0045)
Tangential cutter holder 2N
(SPA-0261)
○○
Urethane form
(Sponge)10mm
Reciprocating cutter
2° x10
(SPB-0086)
Or
Carbide blade 7x15(SPB-0075)
Reciprocating cutter holder 07L
(SPA-0260)
○○○
• Various types of workpiece may exist with the same name. Use the workpiece types in the table
above as a guideline only.
Always make a test cut before cutting actual workpieces. (P.2-17)
Tool (Cutter) Type
Product
number
A unit B unit
Felt
Mat
Hard
Ｍａｔ
Cutti
ng
Mat
Cutter
High-speed, 30°
SPB-0043 ○ ○
Carbide, 30°
SPB-0045 ○ ○
Reciprocating cutter 2° x10
SPB-0086 ○ ○ ○
Carbide blade 7x15
(Reciprocating cutter)
SPB-0075 ○ ○ ○
Swivel Blade
SPB-0030 ○ ○
Cutter holder C with edge.
SPA-0267 ○ ○ ○
Pen
○ ○○○
Grid roller
○○
