Basic Operations
5
5
6
Making a Test Cut
Crease Roller
Swivel Blade
Check Point Cause Remedy See page
Point A contact points do
not match
Blade is mounted eccentrically
Conduct Adjust Eccentricity in tool
adjustments.
P. 6 -4
Lines displaced at Point A
Abnormal angle of crease
roller
Conduct Adjust in tool
adjustments.
P. 6 -9
Crease is weak Press value low
Increase the “PRESSURE” in the
cutting conditions.
P. 2 -11
Crease lines torn along
flutes of corrugate
cardboard.
Y PRESS value in the cutting
conditions is too high.
Align the corrugated cardboard
flutes in the Y-axis direction.
Decrease the “Y PRESS” in the
cutting conditions.
P. 2 - 11
Check Point Cause Remedy See page
Broken lines
Swivel cutter incorrectly
mounted.
Fully tighten the holder screw.
P. 1 - 13
Speed is too slow.
Increase the “SPEED” in the cutting
conditions.
P. 2 -1 2
Press value low
Increase the “PRESSURE” in the
cutting conditions.
P. 2 -11
Corners rounded off
The blade does not protrude
enough.
Increase the amount that the blade
protrudes.
P. 2 - 14
Offset value is too small.
Increase the “OFFSET” in the
cutting conditions.
P. 2 - 11
To Next Page
