2-6
Fixing the Workpiece
Two methods are available to fix a workpiece.
• Fixing the Workpiece by Vacuum Adhesion
• Fixing the Workpiece with Adhesive Tape
Fixing the Workpiece with Adhesive Tape
During swivel cutter / tial cutter used, and set the work(thin packing, industrial rubber, etc) that can not be
properly adsorbed in vacuum , use adhesive tape, and fix the workpiece.
Fix the four edges of the workpiece with the adhesive tape.
• The following table shows the acceptable workpiece thicknesses (Maximum value).
• Four area stickers are stuck on the table. They indicate the maximum effective cutting area. Mount
the workpiece inside this area. The plotter is unable to cut outside the area indicated by the area
stickers.
• Use an adhesive tape that does not leave a residue of glue or tape on the cutting panel.
To Next Page
