2-14
Adjusting the Blade to Match the Workpiece
This section describes how to adjust a tial cutter blade or swivel blade.
Adjusting the tial Cutter
A cutter holder is required to mount the tial cutter.
• It is not possible to adjust a reciprocating cutter blade.
• Handle the blade carefully to avoid injury. For safety, handle the blade with the tweezers supplied.
Head Type Cutter Holder Cutter Applicable Workpiece
Unit B
Cutter holder 2 N
For high-speed, 30°
For carbide, 30°
Workpiece thickness 2 mm max.
To Next Page
