MIMAKI CFL-605RT - Performing a Test Cut

2-17
1
2
Basic Operations
5
5
6
Making a Test Cut
After changing the cutting conditions or tool, make a test cut to check the items listed below. For details, see
"Checking the Tool Status" ( P.2-18).
1
Press the key in LOCAL.
2
Press the key.
• Test cutting starts.
• When the cutting has been completed, the screen returns to LOCAL.
3
Check the cutted test pattern.
• When the result is normal, end the operation.
No. Check Item Check Point
(1)
Are the cutting (drawing)
conditions suitable?
Work is correcly cut or drawing is not smudged.
(2)
Is tool mounted eccentrically? An eccentric tool can cause displacement in the cutting or drawing.
(3)
Do tools match?
When a tial cutter cuts over a drawing, do the drawn and cut patterns
match?
<TEST CUT>
ENTER KEY t o START
<TEST CUT>
A:PEN ** / **
<LOCAL>
A:SWIVEL
