MIMAKI CFL-605RT - Setting Multi-Pass Cutting

3-12
Setting Multi-pass Cutting
Setting Multi-pass Cutting
While changing the press value, can cut the same data up to 9 times for each tool.
This is an effective means of cutting a workpiece that cannot be cut in one pass.
1
Press the key in LOCAL
2
Press and select [MULTI PASS].
3
Press .
4
Press and select TOOL.
• Set value: REC.CUTTER1~2, CUTTER, ROLLER1~3, SWIVEL
5
Press .
6
Press , select the number of times to cut
and press .
• Set value: OFF, 2 to 9 TIMES
• Set the cut start time (Close time P.3-20) that sets the delimiter between data. Multi-pass cutting
starts if the next data is not received within the set time.
Set Item Set value Description
PASS OFF, 2 to 9
Set the number of copies you want to cut.
2nd PRESS
30 g to 1500 g
*1
*1. The set values differ according to the unit.
REC.CUTTER/CUTTER/ROLLER: 500 g to 1500 g(When vibration is on, 1500g fixed)
SWIVEL: 30 g to 1000 g
Sets the press value for the second cut.
3rd PRESS
Sets the press value for the third cut.
4th PRESS
Sets the press value for the fourth cut.
5th PRESS
Sets the press value for the fifth cut.
6th PRESS
Sets the press value for the sixth cut.
7th PRESS
Sets the press value for the seventh cut.
8th PRESS
Sets the press value for the eighth cut.
9th PRESS
Sets the press value for the ninth cut.
• Behind the tool, display the number of
times currently set.
-: OFF
2 ~ 9: Setting
<FUNCT ION>


SET UP [ ENT ]
FUNCTION
<FUNCT ION>


MULT I PASS [ ENT ]
<MULT I PASS>
TOOL : B:REC.CUTTER
<TOOL SELECT>
TOOL : A : SWI VEL /
1
<TOOL SELECT>


PASS : OFF
<MULT I PASS>
PASS : 3T I MES
