Useful Function
5
6
Assigning Pen Numbers
This section describes how to assign pen numbers in the data to tools on the unit.
For this unit, up to six pens can be assigned to each tool.
This example describes how to make the following settings.
Pen 1 (pen number in drawing data) : Set to PEN.
Pen 2 (pen number in cutting data) : Set to REC.CUTTER1.
The following settings allow simultaneous drawing and cutting of Pen 1 and Pen 2 data.
1
Select [PLOT SETTING] of the set up menu.
(1) Press the key in LOCAL.
(2) Press to select [SET UP] and press the key.
(3) Press to select [PLOT SETTING].
(4) Press the key.
2
Press the jog key or to select [PEN
ASSIGN], and ress the key.
• Tool name displays the current settings.
3
Press the jog key or and select the pen
number to be set
• Here select pen number "1".
• Set values: 1 to 6
4
Press the key.
5
Press the jog key or to select unit.
• Here choose the unit "A".
• Set values: A, B
6
Press the key.
7
Press the jog key or to select tool.
• The set values differ according to the mounted tools.
• Here choose the tool "PEN".
• Unit A: PEN, SWIVEL
• Unit B: REC.CUTTER1 to 2, CUTTER, ROLLER1 to 3
8
Press the key.
FUNCTION
<PEN No . SELECT>
No . 1 B : REC . CUTTER1
Tool name
<PEN No . SELECT>
No . 1 B : REC . CUTTER1
<PEN ASS I GN>
No . 1 A : PEN
<PEN ASS I GN>
No . 1 A : PEN
<PLOT SETT I NG>
PEN ASS I GN [ENT]
To Next Page
