3-8
Functions in the Jog Mode
Digitization operation
The coordinates of the plotted figure relative to the origin are displayed on the host computer.
Upon receiving the digitization command (DP;) from the host computer, the plotter is ready for digitization
operation.
To conduct digitization, install a sheet with patterns to select points on it.
1
Set the plotter in the remote mode and make it receive
the digitization command from the host computer.
• The display will change as shown at right.
2
Move the pen with a jog key or
until the pen tip reaches a given point of the pattern.
• The coordinates relative to the origin will be displayed.
• If you set the step to a smaller value using the jog step function, you may select a desired point with
increased accuracy. (
P. 3 - 28 )
3
Press the key.
• The plotter records the point of the pen head.
• The plotter receives the coordinate output command (OD;) from
the host computer.
• The digitization operation is available only with an application software that incorporates a digitization
function. Refer to the instruction manual for the application software for how to use the digitization
function.
<REMOTE> 1356K
B
PEN 20 1 2 0
<REMOTE> 1356K
B
** DI
GITIZE * *
<D I
GITIZE
>mm
X: 100 . 0 Y: 250 . 5
<REMOTE> 1356K
B
** DI
GITIZE * *
